Features

Designed to withstand the rigorous demands of the construction industry.

Can be used on any gas or diesel portable compressor when sized correctly

Features a heavy-duty moisture separator with manual drain for removal of trapped moisture and condensed oil.

Designed to bolt onto most portable compressors.

Expanded metal heat exchanger guard is standard.

Chicago fittings are provided on the inlet and outlet connections for easy attachment to the compressor in the field.

13-foot power cord with alligator clips to connect to the compressor starting battery.

Compact installation does not interfere with vehicle tailgates, etc.

Cools air to within 20° of ambient temperature to optimize moisture removal.

Flat mounting plates are provided to accommodate u-bolt attachment to drawbar frame.

Options

1-Micron coalescing filter with manual drain

Contact for Availability & Pricing

Request a Quote

PHP FormMail Generator - A free tool to create ready-to-use web email forms with file upload, auto-response email, and dependent dropdowns.

Specifications

Maximum Flow 250 CFM
Maximum Operating Pressure 200 psig
Maximum Pressure Drop 5 psig
Fan Power Requirement 17.5 amps, 12 volts DC
Dimensions 30" W x 14" D x 30" H
Weight 50 lbs
